| Swing over bed | 330mm |
| Swing over carriage | 148mm |
| Max length of work piece | 700mm |
| Spindle bore | 38mm |
| Taper of spindle bore | M.T. No.5 |
| External taper of spindle | D1-4 |
| Spindle speed number | 166mm |
| Range of spindle speed | 100-2500r/min |
| X-axis travel | 190mm |
| Z-axis travel | 750mm |
| X-axis rapid speed | 2.5m/min |
| Z-axis rapid speed | 5m/min |
| X-direction min setting unit | 0.01mm |
| Z-direction min setting unit | 0.001mm |
| Number of tool position | 4 |
| Max size of tool holder | 16 x 16mm |
| Diameter of tailstock sleeve | 45mm |
| Travel of tailstock sleeve | 120mm |
| Taper of tailstock sleeve | M.T. No.3 |
| Power of main motor | 3kW |
| Net weight | 650kg |
| Gross weight | 780kg |
| Sizes of package(LxWxH) | 193x114x201cm |
The surface of guideway is delt with quenching and precision grinding, it’s precision has good stability
Simple manipulation and low maintenance cost
Good workmanship, reasonable design and friendly service
Excellent product, easy to use, and the support team was very responsive. Very satisfied with our purchase.
