Model

WLH-DRS1250

Amount of Rollers

Sync 2+

Max.Diameter of Material

Φ1250 mm

Max.Swing Over Slide

Φ600 mm

Max.Length of Work Piece

600 mm

Thickness of Work Piece

0.5-7.0 mm(Aluminum,Copper)

0.5-3.5 mm(Carbon Steel)

0.5-3.0 mm(Stainless Steel)

X Trave

610 mm

Z Trave

780 mm

Spindle Speed

1500 rpm

Taper of Tailstock Quil

MT5

Travel of Tailstock

500 mm

Travel of Tailstock Quil

200 mm

Diameter of Tailstock Quil

Φ85 mm

Amount of Tools/Shank Size

6+1/30x30 mm²

Spindle Motor Power

22 kw

Machining Accuracy

It 6

Overall Dimensions

3600x2500x2200mm
