No. | Name | Unit | Value | |
1 | Nominal Force | KN | 400 | |
2 | Length of worktable | mm | 1600 | |
3 | Distance between Uprights | mm | 1300 | |
4 | Ram stroke | mm | 160 | |
5 | Opening height | mm | 420 | |
6 | Depth of throat | mm | 250 | |
7 | The running speed of ram | No load | Mm/s | 180 |
Full-load | Mm/s | 10 | ||
return | Mm/s | 180 | ||
8 | Main motor | kW | 7.5 | |
9 | Weight | Kg | 3000 | |
10 | Dimension | mm | 2150X1600X2200 | |
High-Precision CNC Closed-Loop Control: Integrates linear scales and electro-hydraulic servo valves managed by the CNC system to achieve outstanding ram repeatability of ±0.01mm.
Energy Efficient & Quiet Operation: Optimized CNC-hydraulic integration lowers oil temperatures, accelerates response times, and reduces energy consumption with smooth, quiet operation.
Robust Structural Integrity: Heavy-duty welded steel frame stress-relieved by annealing, featuring a 210mm throat depth and 380mm daylight opening for maximum structural rigidity.
Canton Fair Featured Model: Proven exhibition performance offering superior reliability and high cost-efficiency for global buyers seeking reliable CNC technology.
