| Parameter | WLH-SRS1250 |
|---|---|
| Max. Diameter of Material | 1250mm |
| Main Motor Power | 22kw servo |
| X Travel | 600mm |
| Z Travel | 650mm |
| Tailstock Force | 35kn |
| Travel of Tailstock | 800mm |
| Amount of Tools | 6 |
| Thickness of Work Piece (Al, Cu) | 0.5-4mm |
| Thickness of Work Piece (C.S) | 0.5-3mm |
| Thickness of Work Piece (SS) | 0.5-2mm |
■ Large-Scale Precision Forming: Effortlessly handles workpieces up to 1250mm max. diameter with 600mm X-travel / 650mm Z-travel, perfect for large and complex industrial components
■ Heavy-Duty Power & Superior Rigidity: Powered by a 22kW main servo motor combined with a 35kN tailstock clamping force (800mm stroke) to guarantee steady performance on hard metals
■ 6-Tool Versatility & Wide Material Compatibility: Equipped with a 6-station tool turret, efficiently spinning Al/Cu (0.5–4mm), Carbon Steel (0.5–3mm), and Stainless Steel (0.5–2mm) for seamless multi-process production
